Proximity Sensors - Industrial
Telemecanique SensorsXSDH607339TF
Telemecanique Sensors XSDH607339TF is an inductive sensor. Specifications include a sensing range of 60 mm, PNP output, IP67 protection, 12V ~ 48V supply, Form 80 x 80 x 40, Plastic housing, and an operating temperature of -40°C to 70°C.
Engineering Specifications
9 of 13 fields available · 69%Verified specifications7 of 9 verified specifications with source evidence
Verification date not recordedView source document
Sensor TypeInductiveVerified · High · Page 1
Sensing MethodNot specified
Sensing Distance60.0 mm
Output TypePNPVerified · High · Page 1
Supply Voltage12V ~ 48V
IP RatingIP67Verified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled ingress-protection context
Excerpt: “IP67”
Extracted Sep 7, 2026View source
Housing MaterialPlasticVerified · High · Page 1
Housing TypeForm 80 x 80 x 40Verified · High · Page 1
Operating Temperature-40°C to 70°CVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled range with explicit °C/°F/K unit
Excerpt: “-40…158 °F”
Extracted Sep 1, 2026View source
Switching Frequency50 HzVerified · High · Page 1
Response TimeNot specified
Current ConsumptionNot specified
AccuracyNot specified
Where to Buy
Best Price
Mouser
$408.062 In Stock · checked Sep 4, 2026
Verify current stock at the retailer before ordering.
All retailer offers (2)
Can’t find the configuration or quantity you need? Request a sensor.
