Proximity Sensors - Industrial
Telemecanique SensorsXS8C4A1PCG13
Telemecanique Sensors XS8C4A1PCG13 is an inductive sensor. Specifications include a sensing range of 20 mm, PNP output, IP67/IP65/IP69K protection, 10-58V supply, Form 40 x 40 x 117, Polybutylene Terephthalate (PBT) housing, and an operating temperature of -25°C to 70°C.
Engineering Specifications
10 of 13 fields available · 77%Verified specifications8 of 10 verified specifications with source evidence
Verification date not recordedView source document
Sensor TypeInductiveVerified · High · Page 1
Sensing MethodNot specified
Sensing Distance20.0 mm
Output TypePNPVerified · High · Page 1
Supply Voltage10-58VVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled voltage with V unit
Excerpt: “10…58 V DC”
Extracted Sep 7, 2026View source
IP RatingIP67, IP65, IP69KVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled ingress-protection context
Excerpt: “IP67, IP65, IP69K”
Extracted Sep 7, 2026View source
Housing MaterialPolybutylene Terephthalate (PBT)
Housing TypeForm 40 x 40 x 117Verified · High · Page 1
Operating Temperature-25°C to 70°CVerified · High · Page 1
Manufacturer datasheetHighPage 1
Evidence: labeled range with explicit °C/°F/K unit
Excerpt: “-13…158 °F”
Extracted Sep 2, 2026View source
Switching Frequency300 HzVerified · High · Page 1
Response TimeNot specified
Current Consumption15 mAVerified · High · Page 1
AccuracyNot specified
Where to Buy
Best Price
Mouser
$178.0587 In Stock · checked Sep 4, 2026
Verify current stock at the retailer before ordering.
All retailer offers (2)
Can’t find the configuration or quantity you need? Request a sensor.
Related Sensors — Potential alternatives
Other Inductive sensors you may consider, including options from other manufacturers.
| MPN | Manufacturer | Description | Range | Price |
|---|---|---|---|---|
| XS1N30NA349TF | Telemecanique | INDUCTIVE SENSOR +OPTIONS | 20.0 mm | $258.69 |
| XS230SANAL2 | Telemecanique | SENSOR, INDUCTIVE PROXIMITY | 15.0 mm | $104.17 |
| XS106B3PBM8 | Telemecanique | INDUCTIVE SENSOR 36VDC 200MA XS | 2.5 mm | $122.95 |
| XS118B3PCM12 | Telemecanique | INDUCTIVE SENSOR XS1 M18, PNP NO | 8.0 mm | $129.38 |
| XS1N18PA349 | Telemecanique | INDUCTIVE PROXIMITY SENSORS XS, | 10.0 mm | $134.35 |
